1.2 - 1.6 GHz
Radar Power Amplifiers are electronic devices that are used to amplify a low-power radio frequency signal. Radar Power Amplifiers from Ciao Wireless are listed below. Use the parametric search tools to narrow down on products by type, frequency, gain, noise figure, power, voltage, application and various other parameters. View product details, download datasheets and get quotes on matching products.
Showing 1–15 of 27 results
-
CA12-2201
CA12-2201
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-2202
CA12-2202
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-2203
CA12-2203
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-2204
CA12-2204
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-2208
CA12-2208
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-2209
CA12-2209
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-2210
CA12-2210
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-2211
CA12-2211
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-2212
CA12-2212
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-3201
CA12-3201
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-3202
CA12-3202
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-3203
CA12-3203
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-3204
CA12-3204
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-3208
CA12-3208
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View -
CA12-3209
CA12-3209
Frequency Range | 1.2 to 1.6 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | LCFB1Quick View
-
