5.4 - 5.9 GHz
Radar Power Amplifiers are electronic devices that are used to amplify a low-power radio frequency signal. Radar Power Amplifiers from Ciao Wireless are listed below. Use the parametric search tools to narrow down on products by type, frequency, gain, noise figure, power, voltage, application and various other parameters. View product details, download datasheets and get quotes on matching products.
Showing 1–15 of 28 results
-
CA56-2001
CA56-2001
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-2002
CA56-2002
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.5
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-2003
CA56-2003
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 1.4
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-2004
CA56-2004
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-2008
CA56-2008
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-2009
CA56-2009
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-2010
CA56-2010
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-2011
CA56-2011
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-2012
CA56-2012
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-3001
CA56-3001
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-3002
CA56-3002
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-3003
CA56-3003
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-3004
CA56-3004
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-3008
CA56-3008
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View -
CA56-3009
CA56-3009
Frequency Range | 5.4 to 5.9 GHz
Gain dB | 22
Flatness dB | ±0.5
Noise dB | 2.0
P-1dB dBm | 10
IP3 dBm | 20
VSWR Input | 2.0:1/1.5:1
VSWR Output | 2.0:1/1.5:1
+12 /+15 VDC Current | 70
Size | C2Quick View
-
