CA910-3043

CA910-3043

Ciao Wireless specialises in low noise and medium power amplifiers and subassemblies for commercial, defence and Hi-Rel applications. Designs are offered from 1 MHz to 52 GHz covering the various standard and speciality narrow and wide bands in-between. Products are available for most applications including low noise amplifiers, medium and high-power amplifiers, narrow, broadband, and ultra-broadband linear and limiting amplifiers, surface mount and KA-band amplifiers.
Category:

Product Specifications

Product Details:

Manufacturer
Description
Ciao Wireless
Radar and Communication Amplifiers
General Parameters:

Frequency Range

Gain dB (Min/Typ)
Flatness dB (Max/Typ)
Noise dB (Max/Typ)
P-1dB dBm (Min/Typ)
IP3 dBm (Typ)
VSWR Input (Max/Typ)
VSWR Output (Max/Typ)
+12 /+15 VDC Current (mA) Nom/Max
Size

9.0 GHz to 10.6 GHz

30/36

±1.0/±0.5

6.0/4.0

33/34

41

2.0:1/1.5:1

2.0:1/1.5:1

1700

XK4
